Front Mount Dump Trailers
5 ton Dump Trailer
Made in Canada - Learn Why It Matters
After incredible demand, were introducing the 3 ½ Dump Trailers’ big brother. It makes perfect mid size dump trailer without breaking the budget. Whether the job is small or large, this Dump Trailer will suit your need.
TRAILER SPECS
GVWR | 4541 kg (9990 lbs) |
Empty Weight | 1343 kg (2955 lbs) |
Payload | 3198 kg (7035 lbs) |
Capacity | 7.22 cu yd (5.52 cu m) |
Size | 80" x 10' |
Deck Height | 28" (str axles) & 24" (optional drop axles) |
Sides | 24" solid steel, plus 12" wood gussets |
Coupler | 2-5/16" Adjustable |
Jack | 7,000 lb Side Wind |
Safety Chains | (2) 5/16" chain with safety hooks |
Axle | (2) 5000 lb Axles |
Brakes | (1) axle - electric |
Fenders | HD Checker Plate |
Suspension | Multi-Leaf Spring |
Doors | Swing & Cam Lock Barn Doors |
Cross Members | every 16" |
Tie Downs | optional |
Frame | 5" C-Channel |
Tires | ST225/75 R15 |
Lights | D.O.T - Grommet Mounted Sealed - Stop, Tail, Turn and Clearance |
Floor | High Tensile Smooth Plate |
Pumpbox | Steel Checker Plate - lockable |
Pump | Monarch Hydraulic Power Pack (weather proof remote) |
Lift Style | 7 ton Front Mount |
Ramp | optional |
Pivot Points | Fully Greaseable Pins |
Electrical Plug | 7 Way - Flat Pin RV Style |
Prep | Sandblasted, Grinding and Chalked |
Primer | Two Coats 2k High Build Epoxy Primer |
Paint | Two Coats 2k Acrylic Polyurethane High Gloss Topcoat |
Colour | Any Standard Colour |
OPTIONS & PACKAGES
Select either a package below OR Customize your trailer from the available option list below. Press continue to receive a quote on your 5 ton Dump Trailer. Click the ‘?’ icon corresponding to each available option for a detailed description.
